Syvecs Honda Civic Type R FK8 - S7+

NOTE: SYVEC'S UNITS ARE MADE TO ORDER. PRICE MAY SUBJECT TO IMPORT TAX.

The Syvecs Honda Type R 2015+ Plug N Play Kit brings a new level of engine management control to the Honda Type R platform, with the worlds first standalone ECU solution.By simply pluging in the kit, a whole new level of control is available allowing some of the following features:

• Flat shifting
• Electronic wastegate control
• Adjustable autoblip (automatic Heel and Toe) even with the manual gearbox using automatic rev matching
• Rolling anti-lag / pit lane limiter strategies, great for building boost on a roll
• 8 x switchable maps with the ability to select desired engine map, boost level, traction and launch control levels through steering wheel buttons
• Control up to 4 additional injectors for high power installations where staged injection may be required.
• Adjustable knock control
• Cruise control
• Live tuning of every aspect of the engine’s calibration.
• Adjustable traction control strategies based on lateral G and individual wheel speed monitoring.
• Adjustable launch control.
• Direct injection and port injection control
• Full Variable Valve Timing control.
• Flex Fuel control.
• Fully functional with every other ECU on the car.
• Closed loop Lambda control.
• Fully adjustable closed loop boost control with launch level adjustments and trims for turbo speed, air charge, engine coolant temp, exhaust gas temps etc..
• Built in data logging using a market leading analysis software of up to 8 hours, with data rates at up to 1000hz.
• Anti-theft and valet modes.
• Super fast connection via RJ45 Ethernet port for live tuning anywhere in the world or even remotely if on track if connected to one of our Wifi modules.
• Configurable engine safety trips on all important parameters like oil temperature, oil pressure.
• Fuel pump control of both main, and sub pumps, as well as relative fuel pressure monitoring and limiting in the event of fuel pressure dropping on boost.
• 4 different Pedal to throttle angle maps with multipliers for different parameters e.g. speed. Again adjustable via steering wheel buttons.
• Configurable individual cylinder closed loop knock control, to suit any cylinder modification with adjustments to frequency, windows for listening and gains for each cylinder.
• Ability to trigger full cylinder shutdown in severe knock conditions.
• Run up to 7bar map sensors.
• Control high or low impendence injectors.
• Ability to fit any type of external sensor to monitor and trigger safety trips from anything from crank case pressure to damper position.
• Ability to use any size DBW throttle body e.g. Chevrolet LS7.
• Wet and Dry – Wet and dry nitrous control with ability to drive solenoids directly and control n20 heaters via pressure monitoring.
• Ability to control any external vehicle features based on sensor inputs e.g. Adjustable rear wing linked to G force or exhaust control valves.
• Connect any race series dash or even one of our Syvecs edition SDM display units.
• View any input live with built in scope up to 1000hz.
